Sumitomo Fusion Splicers

Quantum Type-Q101-CA+™ Core Alignment Fusion Splicers

Sumitomo Quantum Fusion Splicer Logo

The Quantum PLUS is the lightest, smallest, and most advanced core alignment fusion splicer in the industry; yet it’s also rugged with superior dust, shock and water-proof resistance, making it the ideal choice for even the harshest environments.

The Quantum Type-Q101-CA-Plus™ is Sumitomo Electric Lightwave’s enhancement to its industry leading Quantum core alignment fusion splicer, providing the most advanced splicing technology available today. Maintaining all of the qualities and industry first features of the Quantum Type- Q101-CA, the Quantum + reaches new standard levels in speed by reducing heater shrink time from 28 to 14 seconds. This new speed, coupled with the splicer’s patent protected dual independent ovens, makes it the fastest in the industry by far. The built-in dual heater system, with its unprecedented speed, improves splicing efficiency by over 80% for perfectly streamlined, consecutive, and cost effective splices

Quantum Type-Q101-CA-Kit-2R Fusion Splicer Demo Kits
Condition: Like New!
We Have 2 Kits Available Only $8995 Each

Don't Wait - These Won't Last!

Contact FiberOptic Resale Corp

Are you looking for a great refurbished fusion splicer?

We have a variety of Sumitomo fusion splicers in stock. These splicers have been fully tested and calibrated in our in-house lab and are ready to ship.

Refurbished Sumitomo Fusion Splicers

Sumitomo Quantum Core Alignment Fusion Splicers

Sumitomo Quantum Type-Q101-CA Fusion Splicer Front View

Features

  • Industry’s Only Dual Independent Heat Shrink Ovens
  • Industry’s First High Resolution, Fully Navigational Touch Screen Monitor
  • Industry’s Only SD Port for Virtually Unlimited Data Storage
  • Industry’s Only Internet Interface for Remote Maintenance & Software Upgrades
  • Industry’s Only Video Playback
  • Industry’s Lightest Weight & Smallest Footprint Core Alignment Splicer
  • Ruggedized Design for Shock, Water, and Dust Resistance
  • Automatic Splice Start, Arc Calibration, Heater Start and Fiber Identification
  • Hard Carrying Case with Integrated Work Platform
  • Multiple Positional Monitor with Automatic Display Inversion
  • Fiber Holder or Fiber Clamp Selectable
  • Battery Recharges While Splicing
  • Long Life Battery for 200 Splice and Heater Cycles per Charge
  • Lynx2 CustomFit® Splice-On Connector Compatibility
  • Three Year Warranty Included
  • 24-Hour Technical Support via 1-888-SPLICER

Sumitomo Quantum Fusion Splicer Models

Type-Q101-CA-KIT-1
Type-Q101-CA-KIT-2
Type-Q101-CA-KIT-2R
Type-Q101-CA-KIT-2RFH
Type-Q101-CA-KIT-6RSC
Type-Q101-CA-KIT-6RSCFH

Splicer Kit with Accessories (No cleaver)
Splicer Kit with Accessories and FC-6S-C Cleaver
Splicer Kit with Accessories and FC-7R Precision Cleaver
Splicer Kit with Accessories, FC-7R Precision Cleaver and Fiber Holders (250, 900um & LB5)
Splicer Kit with Accessories and FC-6RS-C Precision Cleaver
Splicer Kit with Accessories, FC-6RS-C Precision Cleaver and Fiber Holders (250, 900um & LB5)


Sumitomo Quantum Type-Q101-CA Core Alignment Fusion Splicer Kit Contains

BU-101 | Battery
FHS-025 | 250um Single Fiber Holder
FHS-09 | 900um Single Fiber Holder
ER-10 1 pr | Spare Electrodes
Hand-Held Precision Fiber Cleaver Model Depends on Kit
* FC-6S-C Precision Fiber Cleaver with Scrap Fiber Catcher
* FC-7R Hand-Held Precision Fiber Cleaver with Automatic Blade Rotation and    Catcher
* FC-6RS-C Precision Bench Top Automatic Blade Rotation Cleaver with Catcher
FPS-40-10P 1 pk | Fiber Protection Sleeves (Single Fiber, 40mm, 10 Sleeves) .
FPS-1 1 pk | Fiber Protection Sleeves (Single Fiber, 60mm, 50 Sleeves)
Q101-STH-KIT set | Splice Tray Holder
BC-101 set | Dual Bay Battery Charger, Adapter

Sumitomo Quantum Type-Q101-CA Fusion Splicer Open Top

Sumitomo Fiber Cleavers

Sumitomo FC-6S Fiber Cleaver

Unprecedented Precision…Speed…Performance…and Reliability characterize Sumitomo Electric’s line of fiber cleavers for single fiber or ribbon fiber.

Sumitomo’s patent pending auto blade rotation technology eliminates the time consuming and error prone process of height and blade rotation adjustments, thereby increasing user friendliness, speed, precision, productivity, and the extension of the cleaver’s maximum product life.

Sumitomo Fiber Holders

Sumitomo Fiber Holders

Sumitomo Fiber Holder Features

  • Tightly Controlled Tolerances On Fiber Holders Allow Proper
    Insertion Alignment In The Fusion Splicer
  • Units are Purchased In Pairs
  • Holders Use Magnets To Close the Covers Tightly and Prevent
    Fiber Slippage
